QS300
Seal for Compressor/Blowers
Three-segmented seal
The segmented structure ensures superb followability in the radial direction. The floating structure achieves superb durability, eliminating the need for cooling. Precision machining minimizes leakage to levels comparable to those of contact type segment seals.
Compared with conventional segment seals, this seal consists of a smaller number of parts and is therefore robust. The shaft is hardly subject to wear, and does not require hardening treatment.
The unit structure allows easy installation and handling. A cartridge structure including a sleeve is also available.
Flammable gas and toxic gas can be completely sealed by using two sets of QS300 in a double seal arrangement (QS310) and a buffer gas.
Feature
- Superb followability in the radial direction achieved by the three-segmented structure
- Superb durability with the floating structure
- No cooling required
- Minimal leakage comparable to contact type segment seals achieved by precision machining
- Consists of a smaller number of parts and is more robust than conventional segment seals
- Minimal shaft wear, and no hardening treatment required
- Easy installation and handling achieved by the unit structure. Also available in a cartridge structure including a sleeve.
- Flammable gas and toxic gas completely sealable by using two sets of QS300 in a double seal arrangement (QS310) and a buffer gas
Product specification example
Optimum for conditions of 1 bar (14.5 PSI) max., 3,600 rpm max., and 200 ºC (392 ⁰F) max.
* This product can be used at conditions exceeding the above. For more information, please contact us.
Applicable ranges, performance data and figures can serve only as a guide for selection and therefore in actual use there will be some cases where general specifications cannot be applied due to unknown factors or constraints.
Please check the applicability before use.
The contents are subject to change without notice for improvement.
